IC için otomasyon

Örnek sayınız ve ön hazırlık işleminiz ne olursa olsun, iyon kromatografi sistemleriniz için ihtiyaçlarınızı karşılayabilecek otomasyon çözümünü sizlere sunuyoruz.

Avantajlar Sistemler Tecrübemiz

Öne çıkan özellikler

Metrohm, iyon kromatografi sistemleri için eluent hazırlama ve otomatik numune girişinden tutun, kalibrasyon ve numune hazırlamaya kadar çeşitli otomasyon seçenekleri sunmaktadır. Otomasyon ile analiz tekrarlanabilirliği ve sonuçların kalitesi iyileştirilirken, numune verimini arttırabilirsiniz. Analizleriniz başına düşen zamanın daha az olması, daha düşük maliyet ve daha yüksek işletme karı anlamına gelmektedir.

Uzun örnek serilerinin 7/24 gözetimsiz analizi
Daha fazla sayıda örnek ve analiz başına daha az maliyet
Daha kesin ve doğru sonuçlar
Çok kanallı kullanım: Tek otomasyon ile anyon ve katyon analizleri

Broşür: OMNIS IC – İhtiyaçlarınıza göre özelleştirilmiş modüler iyon kromatografi sistemi (8.000.5539, PDF, 7.4 MB)

Avantajlar

Kapsamlı otomasyon seçenekleri

Metrohm otomasyonlu iyon kromatografi sistem seçenekleri sınır tanımamaktadır: Çok düşük örnek kapasitesinden 200'ün üstünde örnek kapasitesine, çok düşük mikrolitre hacimlerden yarım litreye kadar seçenekler mevcuttur. Neredeyse her çeşit ve şekilde vial, otomasyon sistemleri ile uyum sağlayabilir.

Buna ek olarak, vialleriniz için özel bir çözüm istiyorsanız, bu vialler için uygun örnek tablası tasarlayıp üretebiliyoruz.

Metrohm IC için otomasyon seçenekleri
Otomasyon seçeneği	Avantajlar
Otomatik eluent üretimi	Manuel müdahale olmaksızın sürekli çalışma Hidroksit elüentler için bile stabil tutunma zamanları
Otomasyonlu çok-kanallı analizler	Tek otomasyon ile paralel anyon-katyon analizleri ampler 7/24 gözetimsiz olarak, neredeyse her matriksteki ve çeşitteki örneğin iyonik analizi (konfigürasyona bağlı olarak)
Otomatik Metrohm Inline Örnek Hazırlama (MISP)	En zorlu matrisler için bile (örn. süspansiyonlar, partikül veya protein yüklü matrisler, katı veya gaz matrisler) tam otomatik numune hazırlama
Akıllı enjeksiyon teknikleri	Her türlü akıllı enjeksiyon tekniği kullanılabilir. (full-loop, internal-loop, Metrohm akıllı Parçasal-Loop Enjeksiyon Tekniği (MiPT) ve Metrohm akıllı Pick-up Enjeksiyon Tekniği (MiPuT) analiz verimini ve performansını arttırmayı sağlar).
Otomatik kalibrasyon ve spike	Tek bir çoklu-iyon standardı ile zaman kazandıran ve yüksek hassasiyete sahip otomatik kalibrasyon Sonuçların ve ön-konsantrasyon performansının otomatik ve yüksek kesinlikte doğrulanması. Daha verimli, kesin ve doğru sonuçlar.

Sınırsız konfigürasyon seçenekleri

key visual, IC, ion chromatography, automation, OMNIS IC, OMNIS IC M, OMNIS IC M COND/MSM/MCS/PP/DEG/ DD/ROLC, 210510020, OMNIS IC Autosampler, 210540010, AS Tray, 602040010, 602041500, OMNIS Sample Rack, 602041510, vial, OMNIS software, lab, person, male

Numunelerinizi solüsyon haline getirerek enjeksiyona hazır hale getirmek için kullanılan sıvı işleme ve akıllı enjeksiyon yöntemi seçeneklerinde bir sınırlama yoktur. Pompalar, valfler ya da dozajlama üniteleri ile ilgili hangi konfigürasyon gerekirse gereksin, numunelerinizin soğutmaya ihtiyacı olsun veya hangi akıllı enjeksiyon tekniğine ihtiyaç duyulursa duyulsun, size ihtiyaçlarınızı karşılayacak tam otomasyonlu çözümler sunuyoruz.

Sistemler

OMNIS IC Autosampler Module

2.1054.0010

The OMNIS IC Autosampler automates the sample change in the OMNIS IC System and enables efficient processing of up to 160 vials of 5 mL each, depending on the selected rack. As the first fully integrated autosampler of the new OMNIS IC generation, it is installed directly below the OMNIS IC as standard. It is not a stand-alone device, but an integral part of the OMNIS IC System, which is conveniently controlled via the OMNIS Software.Key features:Compact footprint: Can be placed directly under the OMNIS IC; High sample throughput: 96 x 10 mL vials, 160 x 5 mL vials, 192 x (1500, 700, 300) µL HPLC vials, 384 x 2 mL well format (deep well plate); High speed (30 s/injection of 5 µL); Removable autosampler tray for easy loading and unloading; Interior lighting for easy loading and unloading; Fast and precise xyz needle drive with automatic vial detection; Follow-up light and status display for visual traceability of needle movement and autosampler status; High flexibility for different sample vessels and rack types (including customer-specific racks); Six integrated positions for 50 mL bottles, e.g., for standards or rinsing solutions; Integrated rinsing station and leak detection as standard for maximum safety; Fully integrated into the OMNIS Software; Optional upgrades: 3/2-way valves, dilution station, barcode reader;

OMNIS IC Autosampler Module COOL

2.1054.0020

The OMNIS IC Autosampler COOL automates the sample change in the OMNIS IC System and enables efficient processing of up to 160 vials of 5 mL each, depending on the selected rack. In addition, the OMNIS IC Autosampler Module COOL offers the option of precisely controlling the temperature in the range from 4 °C to 22 °C, enabling a large number of samples to be cooled. The cooling function is ideal for thermally unstable and biochemically relevant samples, for example in the analysis of organic acids, halogenated acetic acids, amino acids, and carbohydrates.Key features:Compact footprint: Can be placed directly under the OMNIS IC; Temperature control from 4 °C to 22 °C; High sample throughput, large quantity of coolable samples: (96 x 10 mL vials, 160 x 5 mL vials, 192 x (1500, 700, 300) µL HPLC vials, 384 x 2 mL well format (deep well plate); High speed (30 s/injection of 5 µL); Removable autosampler tray for easy loading and unloading; Interior lighting for easy loading and unloading; Fast and precise xyz needle drive with automatic vial detection; Follow-up light and status display for visual traceability of needle movement and autosampler status; High flexibility for different sample vessels and rack types (including customer-specific racks); Six integrated positions for 50 mL bottles, e.g., for standards or rinsing solutions; Integrated rinsing station and leak detection as standard for maximum safety; Fully integrated into the OMNIS Software; Optional upgrades: 3/2-way valves, dilution station, barcode reader;

1 / 2

Tüm sistemleri görüntüle (2)

919 IC Autosampler plus

2.919.0020

The 919 IC Autosampler plus fulfills the requirements of laboratories with medium sample numbers. It enables automation of the full range of Metrohm IC instruments.

858 Professional Sample Processor

2.858.0010

The 858 Professional Sample Processor processes samples from 500 µL to 500 mL. The sample transfer takes place either by means of a peristaltic pump on the 850 Professional IC system or with an 800 Dosino.

858 Professional Sample Processor – Pump

2.858.0020

The 858 Professional Sample Processor – Pump processes samples from 500 µL to 500 mL. The sample transfer takes place either with the installed bidirectional two-channel peristaltic pump or with an 800 Dosino.

858 Professional Sample Processor – Pump – Injector

2.858.0030

The 858 Professional Sample Processor – Pump – Injector processes samples from 500 µL to 500 mL. The sample transfer takes place either with the installed bidirectional two-channel peristaltic pump or by means of an 800 Dosino. In addition, a six-way injection valve is available for the sample preparation.

889 IC Sample Center

2.889.0010

The 889 IC Sample Center is a robust Autosampler for high sample throughput, optimized for the challenges of the modern analytic laboratory. It works in accordance with the x-y-z principle and a syringe control with high resolution for precise sample injection. A double needle system enables the penetration of vessel caps and septa. A PEEK injection valve completes the automation system of the 889 IC Sample Center. It is the appropriate automation solution when you have only a very small amount of sample.

889 IC Sample Center – cool

2.889.0020

The 889 IC Sample Center – cool is the appropriate automation solution when you have only a very small amount of sample. In comparison with the 889 IC Sample Center, it possesses in addition a cooling function and is thus the ideal sample changer for biochemically relevant or thermally unstable samples.

863 Compact IC Autosampler

2.863.0010

The 863 Compact IC Autosampler is the ideal help for routine analysis. It enables automation of the full range of Metrohm IC instruments.

800 Dosino

2.800.0010

The 800 Dosino is a drive with write/read hardware for intelligent Dosing Units. With fixed cable (length 150 cm).

800 Dosino

2.800.0020

Drive with write/read hardware for intelligent dosing units. With permanently attached cable (length 0.65 m).

814 USB Sample Processor (1T/1P)

2.814.0010

USB Sample Processor with one workstation and one built-in membrane pump for the automatic processing of routine samples in series with small to medium quantities. In addition to the built-in pump, an additional one (membrane or peristaltic) and up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

814 USB Sample Processor (1T/2P)

2.814.0020

USB Sample Processor with one workstation and two built-in membrane pumps for the automatic processing of routine samples in series with small to medium quantities. In addition to the built-in pumps, up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately. The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

814 USB Sample Processor (1T/0P)

2.814.0030

USB Sample Processor with one workstation for the automatic processing of routine samples in series with small to medium quantities. Up to two pumps (membrane or peristaltic) and three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

814 USB Sample Processor (2T/2P)

2.814.0110

USB Sample Processor with two workstations and two built-in membrane pumps for the automatic processing of routine samples in series with small to medium quantities. In addition to the built-in pumps, two additional pumps (membrane or peristaltic) and up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

814 USB Sample Processor (2T/4P)

2.814.0120

USB Sample Processor with two workstations and four built-in membrane pumps for the automatic processing of routine samples in series with small to medium quantities. In addition to the built-in pumps, up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

814 USB Sample Processor (2T/0P)

2.814.0130

USB Sample Processor with two workstations for the automatic processing of routine samples in series with small to medium quantities. Up to four pumps (membrane or peristaltic) and three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (1T/1P)

2.815.0010

Robotic USB Sample Processor XL with one workstation and one built-in membrane pump for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. In addition to the built-in pump, an additional one (membrane or peristaltic) and up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (1T/2P)

2.815.0020

Robotic USB Sample Processor XL with one workstation and two built-in membrane pumps for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. Up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (1T/0P)

2.815.0030

Robotic USB Sample Processor XL with one workstation for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. Up to two pumps (membrane or peristaltic) and three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (2T/2P)

2.815.0110

Robotic USB Sample Processor XL with two workstations and two built-in membrane pumps for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. In addition to the built-in pumps, up to two additional pumps (membrane or peristaltic) and three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (2T/4P)

2.815.0120

Robotic USB Sample Processor XL with two workstations and four built-in membrane pumps for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. Up to three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head, and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic USB Sample Processor XL (2T/0P)

2.815.0130

Robotic USB Sample Processor XL for the automatic processing of routine samples in series with large quantities and for complex sample preparation or parallel runs. Up to four pumps (membrane or peristaltic) and three dosing devices for Liquid Handling tasks can be connected.Because of the multitude of application variants, rack, stirrer, titration head, robotic arm, Swing Head, and sample vessels must be tailored to the application and ordered separately.The control is "stand alone" using Touch Control. The following software products can be selected for the PC control: tiamo™ titration software, MagIC Net chromatography software, viva voltammetry software, or OMNIS.

815 Robotic Titration Soliprep

2.815.1110

The 815 Robotic Titration is a system for the completely automatic preparation of solid samples that need to be reduced and placed in solution prior to titration.The system consists of:1 x 815 Robotic USB Sample Processor XL1 x 136 Polytron with power supply unit2 x 772 Pump Unit2 x 786 Swing Head1 x 802 Rod stirrer

815 Robotic Flexible Soliprep

2.815.2110

The preparation system for solid samples that need to be homogenized, filtered and decanted in closed vials.The system consists of:1 x 815 Robotic USB Sample Processor XL1 x 136 Polytron with power supply unit1 x 772 Pump Unit1 x 786 Swing Head1 x reinforced 786 Swing Head1 x 800 Dosino

815 Robotic Filtration Soliprep

2.815.3110

The 815 Robotic Filtration Soliprep is a complete system for the completely automatic preparation of samples which need to be homogenized and filtered prior to their determination.The system consists of:1 x 815 Robotic USB Sample Processor XL1 x 136 Polytron with power supply unit1 x 772 Pump Unit1 x 786 Swing Head1 x reinforced 786 Swing Head1 x 800 Dosino

815 Robotic Soliprep for LC

2.815.4110

The 815 Robotic Soliprep for LC is a complete system for the completely automatic preparation of samples which need to be dissolved, homogenized, diluted or filtered prior to their determination. The samples are conveyed directly into the injector of the chromatograph after preparation.Comprised of:1 x 815 Robotic USB Sample Processor XL1 x 136 Polytron with power supply1 x 772 Pump Unit 2 x 786 Swing Head2 x 800 Dosino

889 IC Sample Center Basic

2.889.0030

The 889 IC Sample Center Basic – is a robust Autosampler for high sample throughput, optimized for the challenges of the modern analytic laboratory. It uses the x-y-z principle. A double needle system enables the penetration of vessel caps and septa.The sample transfer takes place either with a peristaltic pump in the IC system or with an 800 Dosino, e.g. when applying the intelligent Partial Loop Injection Technique.Supported with MagIC Net 4.1 and higher.

889 IC Sample Center Basic - cool

2.889.0040

The 889 IC Sample Center Basic – cool is the appropriate automation solution when you have only a very small amount of sample. In comparison with the 889 IC Sample Center Basic, it possesses in addition a cooling function and is thus the ideal sample changer for biochemically relevant or thermally unstable samples.The sample transfer takes place either with a peristaltic pump in the IC system or with an 800 Dosino, e.g. when applying the intelligent Partial Loop Injection Technique.Supported with MagIC Net 4.1 and higher.

941 Eluent Production Module

2.941.0010

The 941 Eluent Production Module enables the automatic production of an eluent. It enables continuous working without manual intervention and guarantees stable retention times. It can be combined with all Metrohm IC instruments and is monitored by MagIC Net.

948 Continuous IC Module, CEP

2.948.0010

Automated hydroxide eluent production takes place with the 948 Continuous IC Module. Isocratic eluents can be produced and gradients can be run.The 948 Continuous IC Module, CEP is comprised of the following parts:948 Continuous IC Module; Eluent Producer Cartridge (EPC, 6.02850.200); Continuous anion trap (CT, 6.02850.100); High-pressure degasser (H-DEG, 6.02850.000); Example methods according to 948 Continuous IC Module manual.

IC equipment: Additional eluent on the Eluent Production Module

6.5330.090

Accessory set for Eluent Production Module. Contains all parts necessary for expansion by one eluent. The level sensor must be ordered in accordance with the application.

IC equipment: Inline Dialysis

6.5330.100

Accessory set for Inline Dialysis. For use with the 858 Professional Sample Processor and an additional 2-channel peristaltic pump.

IC equipment: Inline dilution

6.5330.120

Accessory set for Inline Dilution. For use with the 858 Professional Sample Processor, 800 Dosino and 741 Magnetic Stirrer.

IC equipment: Liquid Handling Station, left

6.5330.130

Accessory set for assembling the Liquid Handling Station on the Professional Sample Processor. The rinsing water supply can be accomplished by means of a peristaltic pump or a Dosino.
